| System Hardware |
|||
| Chipset | Intel 8th to 12th Core CPU | Watchdog | 0-255 seconds/classification is realized by system software |
| Ram | 1*DDR4 SODIMM, Max 32GB; | Power Supply | 9-36V DC IN |
| Hardware monitor | Voltage and CPU temperature monitoring | Storage | 1*Msata+1*HDD/SSD+1*M.2 NVME 2280 |
| OS | |||
| OS | Windows10、Linux | ||
| l/O Ports | |||
| USB | 4xUSB3.0，2xUSB2.0 | Display | 1*HDMI+1*VGA |
| COM | 6*RS232 (Support 4*RS4851422) | MiniPCIE | 2*MINI PCle (WFVBT and 4G) |
| Ethernet | 2* RJ45 Intel i210/i211 GbE | Buttons | 1 x Power+1 x Reset Button. 1 x Clear CMOs Button |
| Environment |
|||
| Vibration Protection | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration | Operating Temp. | -20℃~60℃, with air flow |
| Shock Protection | acceleration 10g/1 1ms | Storage Temp. | -30℃~70℃ |
| Reliability | MTBF≥50000h; MTTR<0.5h | Humidity | 90% @30℃ non-condensing |
| Mechanical |
|||
| Dimension (WxHxD |
240x150x65mm | Material | Auminum alloy fanless design |
| Weight | 2.0kg | Color | Black |
