System Hardware
|
| Chipset |
Intel® 8th/10th Core and celeron Processor |
Watchdog |
0-255 seconds/classification is realized by system software |
| Ram |
4GB DDR4L memory, up to 16GB |
Power Supply |
12V DC IN |
| Storage |
1*Msata+1*HDD/SSD |
Hardware monitor |
Voltage and CPU temperature monitoring |
| OS |
| OS |
Windows 10、Linux |
| l/O Ports |
| USB |
4*USB |
Display |
1*HDMI |
| COM |
2*RS232 |
MiniPCIE |
1*MINI PCle (WFLBT/4G) |
| Ethernet |
6*2.5GbE RJ45 Intel i225V |
Buttons |
1 x Power+1 x Reset Button |
Environment
|
| Vibration Protection |
5-19Hz/1.0mm amplitude; 19-200Hz/1.0gacceleration |
Operating Temp. |
-20℃~60℃, with air flow |
| Shock Protection |
acceleration 10g/1 1ms |
Storage Temp. |
-30℃~70℃ |
| Reliability |
MTBF≥50000h; MTTR<0.5h |
Humidity |
90% @30'c, non-condensing |
Mechanical
|
Dimension (WxHxD
|
209 x150x57 mm |
Material |
Auminum alloy fanless design |
| Weight |
1.35kg |
Color |
Black |
