| System Hardware |
|||
| CPU | MTK MT6771 0cta-core 2.0GHz | Earpiece | Waterproof earpiece |
| Memory | 4GB | Button | Power button.Volume +/-. 1*Customize function key 1*Barcode scanner shortcut key |
| Storage | 64GB | ||
| Camera | 5MP front camera with fixed focus 13MP rear camera with auto focus and LED light |
||
| Speaker | Dual speakers, 1.2W8Ω | LED Indicator | Charging indicator |
| MIC | Waterproof MlC | Sensor | G-sensor,Gyroscope,E-compass, Distance sensor, Motor, Light sensor |
| Display | |||
| LCD Type | 8" TFT-LCD | Luminance | 500 cd'm2,Optional 1000 cdm2 |
| Max.Resoltuion | 1280*800 | Touchscreen | 5-Points projected capacitive touchscreen, Optional AG+AF Or AG+AF+Wet Hand/Glove |
| Cover Glass | Corning Gorilla Glass lll, hardness 7H, light transmittance 85% | ||
| OS | |||
| OS | Android 10 | ||
| l/O Interface | |||
| POGO PIN | 1*POGO PIN(USB+Charging) | DC Jack | 1*DC Jack |
| USB | 1*USB Type C(USB OTG+Charging) 1*USB 2.0, TYPE A |
||
| Video | 1*mini HD | SlM Card Slot | 1*Micro SlM Card Slot |
| Audio | 3.5mm Headphone Jack | TF Card Slot | 1*TF Card Slot, up to 256GB |
| Aviation Plug | 2*Aviation plugs for RS232/USB/CAN/RJ45 | Ethernet | 1*RJ45, 100MbpS |
| Communication | |||
WNAN |
GSM: B2B3B5/B8 WCDMA: B1/B2/B5B8 TD-SCDMA:B38B39B40VB41 CDMA2000 LTE-FDD:B1/B2/B3VB4/B5B7/B8 LTE-TDD: B38B39VB40VB41 |
WIFI | 802.11abvginac,2.4G+5G Dualband WFl |
| Bluetooth | Bluetooth v2.1+EDR3.0+HS/4.1 LE | ||
| GNSS | MT6631 GPS+BD+GLonass | ||
| Extended Functions | |||
| NFC | 13.56Mhz 14443A14443B15693 | Barcode Scanner | Optional 1Dv2D barcode scanner, 2 choose 1 |
| Fingerprint | Optional fingerprint recognition | RFIDUHF-Rfd | Optional |
| Power | |||
| Power Input |
5VDC Input.5V/3A power adapter Optional 5-24v DC power input, no builtinbattery power supply |
Battery | 8500mAh,3.8vremovable Li-lon battery |
| Battery Life | 10 hours (Play 1080P video under LCD 50% backlight) |
||
| Environment |
|||
| Drop | 1.2m free fall to the wooden floor | Operating Temp. | -10℃~50℃ |
| IP Rating | IP67 | Storage Temp. | -30℃~70℃ |
| Certificate | |||
| Certificate | CE、ROHS、UN38.3、MSDS | ||
| Mechanical |
|||
| Dimension (WxHxD |
227*142.4*22.9mm | ||
| Weight | 0.80kg | Color | Black |
| Accessory | |||
| Accessory | Hand strap, Type-C OTG cable, 5V3A power adapter | ||
| Optional Accessory | Docking, Vehide bracket, Vehicle charger, Passive touch pen, Type-C data cable, Vehicle charging bracket | ||
